| Art No | Size / mm d x s |
Packing unit / Pouch | Inner Diameter (di) | Water Content (I/m) |
| 1701 SP2001 D | 20 x 3.4 | 25 | 13.2 | 0.137 |
| 1701 SP2002D | 25 x 4.2 | 25 | 16.6 | 0.216 |
| 1701 SP2003D | 32 x 5.4 | 10 | 21.2 | 0.353 |
| 1701 SP2004D | 40 x 6.7 | 10 | 26.6 | 0.555 |
| 1701 SP2005D | 50 x 8.3 | 5 | 33.4 | 0.876 |
| 1701 SP2006D | 63 x 10.5 | 5 | 42.0 | 1.385 |
| 1701 SP2007D | 75 x 12.5 | 4 | 50.0 | 1.963 |
| 1701 SP2009D | 90 x 15.0 | 3 | 60.0 | 2.826 |
| 1701 SP2010D | 110 x 18.3 | 2 | 73.4 | 4.229 |
| 1701 SP2012D | 125 x 20.8 | 1 | 83.4 | 5.460 |
| 1701 SP2016D | 160 x26.6 | 1 | 106.8 | 8.954 |
| Art. No. | Size / mmd x s | Packing unit / Pouch | Inner Diameter (di) | Water Content (I/m) |
| 1701 SP1601D | 20 x 2.8 | 25 | 14.4 | 0.163 |
| 1701 SP1602D | 25 x 3.5 | 25 | 18.0 | 0.254 |
| 1701 SP1603D | 32 x 4.4 | 10 | 23.2 | 0.423 |
| 1701 SP1604D | 40 x 5.5 | 10 | 29.0 | 0.660 |
| 1701 SP1605D | 50 x 6.9 | 5 | 36.2 | 1.029 |
| 1701 SP1606D | 63 x 8.6 | 5 | 45.8 | 1.647 |
| 1701 SP1607D | 75 x 10.3 | 4 | 54.4 | 2.323 |
| 1701 SP1609D | 90 x 12.3 | 3 | 65.4 | 3.358 |
| 1701 SP1610D | 110 x 15.1 | 2 | 79.8 | 4.999 |
| 1701 SP1612D | 125 x 17.1 | 1 | 90.8 | 6.472 |
| 1701 SP1616D | 160 x 21.9 | 1 | 116.2 | 10.599 |
| Art. No. | Size / mm d x s | Packing unit / Pouch | Inner Diameter (di) | Water Content (l/m) |
|---|---|---|---|---|
| 1701SP1001D | 20 x 1.9 | 25 | 16.2 | 0.206 |
| 1701SP1002D | 25 x 2.3 | 25 | 20.4 | 0.327 |
| 1701SP1003D | 32 x 2.9 | 10 | 26.4 | 0.539 |
| 1701SP1004D | 40 x 3.7 | 10 | 32.6 | 0.834 |
| 1701SP1005D | 50 x 4.6 | 5 | 40.8 | 1.307 |
| 1701SP1006D | 63 x 5.8 | 5 | 51.4 | 2.074 |
| 1701SP1007D | 75 x 6.8 | 4 | 61.4 | 4.252 |
| 1701SP1008D | 90 x 8.2 | 3 | 73.6 | 6.359 |
| 1701SP1009D | 110 x 10 | 2 | 90 | 8.199 |
| 1701SP1010D | 110 x 10 | 2 | 90.0 | 6.359 |
| 1701SP1012D | 125 x 11.4 | 1 | 102.2 | 8.199 |
| 1701SP1016D | 160 x 14.6 | 1 | 130.8 | 13.430 |
| 1701SP1020D | 200 x 18.2 | 1 | 163.6 | 21.010 |
